WIDE BUCKET

Wide Bucket Website 01 01

PRODUCT FEATURES

  • Pins are included as a standard to suit the intended excavator
  • Bolt-on cutting edge is standard for all 5-Ton up to 20-Ton wide buckets
  • 1-year warranty
  • All prices exclude GST
OAWB-01-900
$1,056
excluding GST

1-1.9T WIDE BUCKET
900MM

Product code OAWB-01-900
Weight (kg) 66
Width (mm) 900
Capacity struck (m3) 0.060
Capacity heaped (m3) 0.079
OAWB-02-1100
$1,447
excluding GST

2-2.9T WIDE BUCKET
1100MM

Product code OAWB-02-1100
Weight (kg) 90
Width (mm) 1100
Capacity struck (m3) 0.090
Capacity heaped (m3) 0.120
OAWB-03-1200
$1,518
excluding GST

3-3.9T WIDE BUCKET
1200MM

Product code OAWB-03-1200
Weight (kg) 106
Width (mm) 1200
Capacity struck (m3) 0.120
Capacity heaped (m3) 0.160
OAWB-05-1400
$2,288
excluding GST

4-5.9T WIDE BUCKET
1400MM

Product code OAWB-05-1400
Weight (kg) 237
Width (mm) 1400
Capacity struck (m3) 0.220
Capacity heaped (m3) 0.280
OAWB-05-1500
$2,354
excluding GST

4-5.9T WIDE BUCKET
1500MM

Product code OAWB-05-1500
Weight (kg) 245
Width (mm) 1500
Capacity struck (m3) 0.230
Capacity heaped (m3) 0.300
OAWB-08-1600
$2,816
excluding GST

6-9.9T WIDE BUCKET
1600MM

Product code OAWB-08-1600
Weight (kg) 295
Width (mm) 1600
Capacity struck (m3) 0.300
Capacity heaped (m3) 0.400
OAWB-12-1800
$5,280
excluding GST

10-14.9T WIDE BUCKET
1800MM

Product code OAWB-12-1800
Weight (kg) 553
Width (mm) 1800
Capacity struck (m3) 0.540
Capacity heaped (m3) 0.710
OAWB-20-2000
$7,744
excluding GST

15-23.9T WIDE BUCKET
2000MM

Product code OAWB-20-2000
Weight (kg) 887
Width (mm) 2000
Capacity struck (m3) 0.820
Capacity heaped (m3) 1.070
OAWB-30-2200
$13,376
excluding GST

30T WIDE BUCKET
2200MM

Product code OAWB-30-2200
Weight (kg) 1346
Width (mm) 2200
Capacity struck (m3) 1.400
Capacity heaped (m3) 1.600
IMG 0383 01 v2 zoom icon
IMG 7783 01 zoom icon
IMG 5871 zoom icon
IMG 2313 zoom icon
IMG 2355 zoom icon

Request a Quote

Get in touch with us anytime for your enquiry, we are always available.
